AXIS M3077 6 Megapixel Outdoor Network Camera - Color - Dome - White

Name: AXIS M3077 6 Megapixel Outdoor Network Camera - Color - Dome - White
Brand: AXIS
SKU: 9AX680
Price: 729.96 USD
Availability: InStock

AXIS

PCN#

9AX680

MFG#

02018-001

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$729.96

Extended & Accidental Damage Protection Plans Available Details

2-Year $66.99

3-Year $89.99

Free Shipping

Estimated Shipment:

Product Highlights:

65.62 ft Infrared Night Vision
H.264 (MPEG
4 Part 10/AVC), H.265 (MPEG
H Part 2/HEVC), H.264, H.265, MJPEG
2560 x 1920
1.56 mm Fixed Lens
60 fps
RGB CMOS
Pendant Mount, Conduit Mount, Ceiling Mount, Pole Mount, Wall Mount, Corner Mount, Lighting Track Mount, Parapet Mount
IK10
IP66

Product Condition: New and Factory Fresh

Limited Warranty5 Year

Shipping Weight: 3 lbs.

AXIS M3077 6 Megapixel Outdoor Network Camera - Color - Dome - White

Overview

Tech Specs

Specifications

Manufacturer	Axis Communications
Manufacturer Part Number	02018001
Manufacturer Website Address	http://www.axis.com
Brand Name	AXIS
Product Series	M30
Product Model	M3077
Product Name	M3077-PLVE Network Camera
Marketing Information	6 MP outdoor-ready with 360° panoramic view and audio capture: With its 6 MP sensor, AXIS M3077-PLVE offers excellent image quality and a complete 180° or 360° overview, indoors or out, around the clock. It features two built-in microphones allowing for audio surveillance and detection. This compact mini dome offers dewarped views such as panorama, quad, corner, and corridor views directly from the camera. It includes Axis Lightfinder and Axis Forensic WDR for true colors and great details in challenging light or near darkness. And, Axis OptimizedIR for surveillance in pitch darkness.
Product Type	Network Camera

Technical Information

HD Recording	Yes
Night Vision	Yes
Night Vision Distance	65.62 ft
Night Vision Type	Infrared

Display & Graphics

Image Sensor Type	RGB CMOS
Color Supported	Color
Field of View	Horizontal field of view: 183° Vertical field of view: 183°
Effective Camera Resolution	6 Megapixel

Video

Video Formats	H.264 (MPEG-4 Part 10/AVC) H.265 (MPEG-H Part 2/HEVC) H.264 H.265 MJPEG
Maximum Video Resolution	2560 x 1920
Maximum Frame Rate	60 fps

Lens

Lens Type	Fixed
Maximum Focal Length	1.56 mm
Lens Included	Yes
Maximum Aperture	f/2

Exposure

Shortest Shutter Speed	1/16000 Second
Longest Shutter Speed	1 Second

Network & Communication

Connectivity Technology	Wired
Remote Management	Yes

Storage

Storage Type

Memory Card

Interfaces/Ports

Network (RJ-45)

Yes

Power Description

Power Source Type

PoE

Physical Characteristics

Mount Type	Pendant Mount Conduit Mount Ceiling Mount Pole Mount Wall Mount Corner Mount Lighting Track Mount Parapet Mount
Form Factor	Dome
Color Family	White
Product Color	White
Height	2.6"
Diameter	5.9"
Weight (Approximate)	1.54 lb

Environmental Conditions

Minimum Operating Temperature	-40°F (-40°C)
Maximum Operating Temperature	122°F (50°C)
Maximum Operating Humidity	100%

Miscellaneous

Features	Built-in IR LED Removable IR Cut-off Filter Day/Night Motion Detection Tampering Alarm SD Card Local Storage Multi-view Stream Automatic White Balance Auto Gain Control Privacy Masking Video Management System PTZ Wide Dynamic Range Built-in Microphone Audio Detection Noise Reduction
Indoor/Outdoor	Outdoor
Package Contents	M3077-PLVE Network Camera Installation Guide Windows Decoder 1-user license Drill Hole Template Cable Gaskets Connector Guard I/O Connector RESISTORX TR20 bit Mounting Bracket Cable Hole Lid View Protector
Impact Protection Rating	IK10
Ingress Protection Rating	IP66
Country of Origin	Thailand
NDAA Compliant	Yes

Warranty

Limited Warranty

5 Year
