Axiom 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN

Name: Axiom 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN
Brand: AXIOM
SKU: 9LU770
Price: 640.07 USD
Availability: InStock

AXIOM

PCN#

9LU770

MFG#

540-BBRN-AX

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$640.07

Extended & Accidental Damage Protection Plans Available Details

2-Year $66.99

3-Year $89.99

Free Shipping

Estimated Shipment:

Product Highlights:

PCI Express 3.0 x8
5 GB/s Data Transfer Rate
Intel XL710AM2
2 Port(s)
Optical Fiber
40GBase
X
QSFP+
Plug
in Card

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 1 lbs.

Axiom 40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN

Overview

Tech Specs

Specifications

Manufacturer	Axiom Memory Solutions
Manufacturer Part Number	540-BBRN-AX
Manufacturer Website Address	http://www.axiommemory.com
Brand Name	Axiom
Product Name	40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN
Marketing Information	Features The Axiom QSFP+ PCIe 3.0 x8 40Gbs Fiber Network Adapter is designed for Servers and high-end appliances. They offer simple integration into any PCI Express X8 to 40 Gigabit Networks. Based on Intel XL710AM Ethernet controller with two fully integrated Gigabit Ethernet Media Access Control (MAC) and XLPPI Interfaces, the Axiom QSFP+ NIC cards are the ideal solution for implementing multiple network segments, mission-critical high-powered networking applications and environments within high performance servers. Key Features: Network Virtualization offloads for VXLAN and NVGRE Unified Networking Providing a single wire for LAN and storage: NAS (SMB, NFS) and SAN (iSCSI,FCoE) Virtual Bridging Support - VEPA/802.1Qbg,BPE/802.1Qbh Physical Functions - Up to 8 per port Support for 128 Virtual Device Queues (VMDq) per port Hardware Queue Pairs - Up to 1.5K (non-RDMA); up to 256K (RDMA) Virtualization - Alleviating hypervisor I/O bottlenecks by providing flow separation for Virtual Machines Includes Full Height and Half Height Mounting Brackets
Product Type	40Gigabit Ethernet Card

Technical Information

Chipset Manufacturer	Intel
Chipset Model	XL710AM2

Interfaces/Ports

Host Interface	PCI Express 3.0 x8
Total Number of Ports	2

I/O Expansions

Expansion Slot Type

QSFP+

Media & Performance

Media Type Supported	Optical Fiber
Data Transfer Rate	5 GB/s

Network & Communication

Network Technology

40GBase-X

Physical Characteristics

Form Factor	Plug-in Card
Height	6.5"
Width	0.5"
Depth	2.7"
Weight (Approximate)	4.96 oz

Miscellaneous

Package Contents	40Gbs Dual Port QSFP+ PCIe 3.0 x8 NIC Card for Dell - 540-BBRN Full Height Mounting Brackets Half Height Mounting Brackets
Device Supported	NAS Storage Device/Server

Warranty

Limited Warranty

3 Year
