ATEN HDMI HDBaseT Receiver with Dual Output (4K@100m) (HDBaseT Class A)

Name: ATEN HDMI HDBaseT Receiver with Dual Output (4K@100m) (HDBaseT Class A)
Brand: ATEN
SKU: 09TD68
Price: 284.14 USD
Availability: InStock

ATEN

PCN#

09TD68

MFG#

VE814AR-ATA

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$284.14

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

1 Output Device
492.13 ft Range
1
2 x HDMI Out
4K
4096 x 2160
Twisted Pair
Category 6a
Rack
mountable

Product Condition: New and Factory Fresh

Shipping Weight: 3 lbs.

ATEN HDMI HDBaseT Receiver with Dual Output (4K@100m) (HDBaseT Class A)

Overview

Tech Specs

Specifications

Manufacturer	ATEN Technology, Inc
Manufacturer Part Number	VE814ARATA
Manufacturer Website Address	http://www.aten.com/us/en/
Brand Name	ATEN
Product Model	VE814AR-ATA
Product Name	HDMI HDBaseT Receiver with Dual Output (4K@100m) (HDBaseT Class A)
Marketing Information	ATEN VE814AR is an HDBaseT Video Receiver that is capable of receiving HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN2L-2910 Cat 6 cable.This HDCP 2.2-compliant receiver meets the HDMI Specification, including 3D, Deep Color, the maximum data rate of (10.2 Gbps), and 4K video quality up to 100 m. The VE814AR supports RS-232 and IR signaling pass-through, allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE814AT). In addition, it supports Long Reach Mode that extends HDMI signals up to 150 m, 1080p, via a single Cat 5e/6 cable. The VE814AR is a powerful solution for where digital signage is required, such as bars, educational spaces, and public transportation stations, allowing display of identical contents at different spots.
Product Type	Video Extender Receiver

Technical Information

Connectivity Technology	Wired
Number of Output Devices Supported	1
Maximum Operating Distance	492.13 ft

Video

Graphics Modes	4K
Maximum Video Resolution	4096 x 2160

Interfaces/Ports

HDMI Out	Yes
Number of Network (RJ-45) Ports	1
Number of HDMI Outputs	2

Media & Performance

Media Type Supported	Twisted Pair
Twisted Pair Cable Standard	Category 6a

Physical Characteristics

Receiver Height	1.14"
Receiver Width	3.98"
Receiver Depth	5.35"
Form Factor	Rack-mountable
Receiver Weight (Approximate)	1.04 lb

Miscellaneous

Package Contents

HDMI HDBaseT Receiver with Dual Output (4K@100m) (HDBaseT Class A)
1 x RS-232 Terminal Block
1 x Power Adapter
1 x User Instructions
