Asus RS720Q-E10-RS8U Barebone System - 2U Rack-mountable - Socket LGA-4189 - 2 x Processor Support - Intel 3rd Gen

Name: Asus RS720Q-E10-RS8U Barebone System - 2U Rack-mountable - Socket LGA-4189 - 2 x Processor Support - Intel 3rd Gen
Brand: ASUS
SKU: 8TQ054
Price: 7054.08 USD
Availability: InStock

ASUS

PCN#

8TQ054

MFG#

RS720Q-E10-WOCPU005Z

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$7,054.08

Extended & Accidental Damage Protection Plans Available Details

2-Year $418.99

3-Year $535.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel C621A Chip
6 TB DDR4 SDRAM DDR4
3200/PC4
25600 Maximum RAM Support
16.0 Total Memory Slots
Serial ATA RAID Supported, Serial Attached SCSI (SAS) Controller
ASPEED AST2600 64 MB Graphic(s)
Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze)
Gigabit Ethernet
Intel Optane Memory Ready
2 USB 3.0 Port(s)
2 x 3000 W

Product Condition: New and Factory Fresh

Shipping Weight: 1 lbs.

Asus RS720Q-E10-RS8U Barebone System - 2U Rack-mountable - Socket LGA-4189 - 2 x Processor Support - Intel 3rd Gen

Overview

Tech Specs

Specifications

Manufacturer	ASUS Computer International
Manufacturer Part Number	RS720Q-E10-WOCPU005Z
Manufacturer Website Address	http://usa.asus.com
Brand Name	Asus
Product Model	RS720Q-E10-RS8U
Product Name	RS720Q-E10-RS8U Barebone System
Marketing Information	Great Scalability and High Performance Computing (HPC) with 4 nodes in a 2U Rack Sever ASUS RS720Q-E10-RS8U is the ideal multi-node server powered by 3rd Gen Intel® Xeon Scalable processors, with each node supporting up to 16 DIMM, one PCIe® 4.0 slot, one OCP 3.0 and two M.2, and a total of eight NVMe/SAS/SATA drives. 3rd Gen Intel Xeon Scalable processors The RS720Q-E9-RS8-S is built with the latest Intel® Xeon® Processor Scalable Family with 16 DDR4 Memory up to 3200MHz, and designed for the demand of high scalability, high density computing, and wide range of existing and emerging workloads. PCIe 4.0 Ready PCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. Cooling Solutions Air or liquid-cooled solutions. Asetek's Direct-to-Chip (D2C) liquid-cooling technology achieving lower power-usage effectiveness (PUE) and optimized TCO for data centers. Enhanced Security PFR FPGA as the platform Root-of-Trust solution for firmware resiliency Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.
Product Type	Barebone System

Processor

Number of Nodes	4
Number of Processors Supported	2
Processor Socket	Socket LGA-4189
Processor Supported	Xeon Platinum Xeon Gold Xeon Silver Xeon Bronze
Processor Manufacturer	Intel
Processor Generation	3rd Gen
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C621A

Memory

Maximum Memory Supported	6 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-3200/PC4-25600
Total Number of Memory Slots	16.0
Intel Optane Memory Ready	Yes

Storage

Supported Storage Drive Interfaces

Serial ATA
SAS

Controllers

Controller Type	Serial ATA Serial Attached SCSI (SAS)
RAID Supported	Yes

Display & Graphics

Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2600
Graphics Memory Capacity	64 MB

Network & Communication

Ethernet Technology

Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	8
Total Number of Expansion Slots	2.0
Number of PCI Express x16 Slots	2

Interfaces/Ports

Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of VGA Ports	1

Power Description

Input Voltage	230 V AC
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	3000 W

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	2U
Height	3.5"
Width	17.5"
Depth	31.5"
Weight (Approximate)	78.26 lb

Miscellaneous

Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
