SERVER 1U RACK INTEL C262 32GB 16GB 8GB UDIMM TPM-SPI

Name: SERVER 1U RACK INTEL C262 32GB 16GB 8GB UDIMM TPM-SPI
Brand: ASUS
SKU: NP0503
Price: 1163.1 USD
Availability: InStock

ASUS

PCN#

NP0503

MFG#

RS300-E12-RS4-1G4

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$1,163.10

Extended & Accidental Damage Protection Plans Available Details

3-Year $143.99

2-Year $107.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel C262 Chip
128 GB DDR5 SDRAM DDR5
4400/PC5
35200 Maximum RAM Support
4 Total Memory Slots
Serial ATA/600 Controller
ASPEED AST2600 64 MB Graphic(s)
4 3.5" Bay(s)
Network (RJ
45)
1 M.2 Interface(s)
Processor Support (Xeon, Pentium)
Gigabit Ethernet
Windows Server 2025, Red Hat Enterprise Linux, SuSE Linux Enterprise Server Supported Operating System
2 USB 3.2 Gen 1 Port(s)
2 x 450 W

Product Condition: New and Factory Fresh

Shipping Weight: 34 lbs.

Asus RS300-E12-RS4-1G4 Server Barebone System - 1U Rack-mountable - Socket LGA-1700 - 1 x Processor Support - Intel Xeon

Overview

Tech Specs

Specifications

Manufacturer	ASUS Computer International
Manufacturer Part Number	RS300-E12-RS4-1G4
Manufacturer Website Address	http://usa.asus.com
Brand Name	Asus
Product Series	RS300-E12
Product Model	RS300-E12-RS4-1G4
Product Name	RS300-E12-RS4-1G4 Server Barebone System
Marketing Information	RS300-E12-RS4 ASUS RS300-E12-RS4 in an Intel^®Xeon^®E-2400 and Intel^®Xeon^®6300 1U server with support for four DDR5 ECC UDIMM, four NVMe, one M.2, one PCIe^®5.0 slot and one PCIe 4.0 slot, plus dual LAN, 80 PLUS^®Platinum redundant power supplies, Intel Platform Firmware Resilience (PFR), onboard ASUS ASMB11-iKVM and chassis-intrusion alert. Key Features Powered by eight-core Intel Xeon E-2400-series and Intel Xeon 6300 series processor with support for up to 95 W TDP Four 3.5-inch or 2.5-inch hot-swap drives on front panel and one M.2 to enable extensive storage Up to one PCIe 5.0 slots and one PCIe 4.0 proprietary slot to drive higher bandwidth High power efficiency with redundant 450 W 80 PLUS Platinum power supplies Dual Intel I210-AT gigabit Ethernet with teaming support Onboard ASUS ASMB11-iKVM for out-of-band management with ASPEED AST2600 controller Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency Chassis-intrusion for enhanced physical security Intel Xeon E-2400 processors/Intel Xeon 6300 processors Designed for small- to medium-sized businesses (SMBs) and cloud-service providers, offering robust and secure solutions. These processors support up to eight cores and 16 threads, with a maximum frequency of 5.6 GHz and a 95 W TDP, ensuring rapid data processing and application responsiveness. They support up to 128 GB of DDR5 4400 MT/s memory (Intel Xeon E-2400) or up to 4800 MT/s memory (Intel Xeon 6300) and PCIe 5.0 interfaces, providing server-grade 24/7 reliability for business-critical services and customer data, and cost-effective performance for entry-level bare-metal cloud services. PCIe 5.0 ready Faster storage, graphics and networking capabilities PCI Express® (PCIe®) 5.0 delivers 32GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data center. Redundant Platinum PSU support RS300-E12-RS4 supports redundant 450W 80 PLUS Platinum power supplies, which are 96%+ efficient, directly reducing operating costs and capital expenses. The 1+1 power-supply design allows the server to keep working even if one power supply requires maintenance, enabling uninterrupted operation.
Product Type	Server Barebone System

Processor

Number of Processors Supported	1
Processor Socket	Socket LGA-1700
Processor Supported	Xeon Pentium
Processor Manufacturer	Intel
Processor Type	Xeon
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C262

Memory

Maximum Memory Supported	128 GB
Memory Technology	DDR5 SDRAM
Memory Standard	DDR5-4400/PC5-35200
Total Number of Memory Slots	4

Storage

Supported Storage Drive Interfaces	Serial ATA III
Supported Storage Drive Types	HDD

Controllers

Controller Type

Serial ATA/600

Display & Graphics

Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2600
Graphics Memory Capacity	64 MB
Graphics Memory Accessibility	Shared

Network & Communication

Ethernet Technology

Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	5
Number of External 5.25" Bays	1
Number of 3.5" Bays	4
Total Number of Expansion Slots	3
Number of PCI Express x4 Slots	1
Number of PCI Express x8 Slots	1
Number of PCI Express x16 Slots	1
Number of M.2 Interfaces	1

Interfaces/Ports

Total Number of USB Ports	5
Number of USB 3.2 Gen 1 Ports	2
Number of USB 3.2 Gen 2 Ports	3
Number of Serial Ports	1
Network (RJ-45)	Yes
Number of Network (RJ-45) Ports	2
VGA	Yes
Number of VGA Ports	2

Operating System

Operating System Supported

Windows Server 2025
Red Hat Enterprise Linux
SuSE Linux Enterprise Server

Power Description

Number of Power Supplies Installed	2
Maximum Power Supply Wattage	450 W

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	1U
Height	1.7"
Width	17.3"
Depth	19.6"
Weight (Approximate)	33.51 lb

Miscellaneous

Environmental Compliance

Restriction of Hazardous Substances (RoHS)
