APC Symmetra RM 6kVA UPS

Name: APC Symmetra RM 6kVA UPS
Brand: APC
SKU: LB1133
Price: 12690.58 USD
Availability: InStock

APC

PCN#

LB1133

MFG#

SYH6K6RMT-P1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$12,690.58

Extended & Accidental Damage Protection Plans Available Details

3-Year $1,672.99

2-Year $1,115.99

Estimated Shipment:

Product Highlights:

10U Rack
mountable
3 Hour Recharge
12.30 Minute Stand
by
208 V Input
120 V AC, 208 V AC Output
Sine Wave
Serial Port
12 x NEMA 5
20R, 2 x NEMA L6
20R Receptacle(s)
14 x Battery/Surge Outlet
SNMP Manageable

Product Condition: New and Factory Fresh

Limited Warranty2 YearAdditional Warranty Information2 years repair or replace, optional on-site warranties available, optional extended warranties available

Shipping Weight: 437 lbs.

APC Symmetra RM 6kVA Scalable to 6kVA N+1 208/240V w/208 to 120V Step-Down Transformer

Overview

Tech Specs

Specifications

Manufacturer	Schneider Electric SA
Manufacturer Part Number	SYH6K6RMT-P1
Manufacturer Website Address	http://www.schneider-electric.com
Brand Name	APC by Schneider Electric
Product Line	Symmetra
Product Name	Symmetra RM 6kVA UPS
Marketing Information	Highly available single phase UPS features redundant and scalable double-conversion on-line power protection
Product Type	Double Conversion Online UPS

Technical Information

Plug/Connector Type	NEMA L6-30P 30A
Receptacle Type	NEMA L6-30P 30A
Receptacle Detail	12 x NEMA 5-20R 2 x NEMA L6-20R
Number of Battery & Surge Outlets	14
Bypass Switch	Automatic & Manual
Emergency Power OFF	Yes
Cord Length	10 ft

Power Description

Load Capacity (VA)	6000 VA
Load Capacity (Watt)	4200 W
Input Voltage	208 V
Output Voltage	120 V AC 208 V AC
Waveform Type	Sine Wave

Management

Network Management	SNMP Manageable
Alarm	On Battery Low Battery Configurable Delay
Battery Management	Intelligent Battery Management

Interfaces/Ports

Serial Port	Yes
Network (RJ-45)	Yes
Total Number of Expansion Slots	1

Battery Information

Battery Characteristics	Spill-proof, Maintenance-free
Battery Chemistry	Lead Acid
Backup/Run Time (Full Load)	12.30 Minute
Backup/Run Time (Half Load)	29.10 Minute
Typical Battery Recharge Time	3 Hour
Hot Swappable	Yes

Environmental Conditions

Maximum Operating Temperature	113°F (45°C)
Thermal Dissipation	741.18 W

Physical Characteristics

Color Family	Black
Product Color	Black
Height	17.5"
Width	19"
Depth	28.7"
Rack Height	10U
Form Factor	Rack-mountable
Mounting Preference	Lower
Mounting Location	Front
Weight (Approximate)	389.82 lb

Miscellaneous

For Country/Region	United States
Package Contents	Symmetra RM 6kVA UPS CD with software Rack mounting brackets Rack mounting support rails User manual
Additional Information	Automatic restart of loads after UPS shutdown Cold-start capable Configurable for N+1 internal redundancy Field-replaceable power distribution panel Generator Compatible Hot-swappable intelligence modules Hot-swappable power modules InfraStruXure Manager Compatible Plug-and-Play external batteries Programmable Frequency Scalable Power Capacity User-replaceable intelligence modules User-replaceable power modules
Certifications & Standards	CSA
Product Take Back Program	No
RoHS Exemption Information	https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SYH6K6RMT-P1_ROHS_DECLARATION&p_FileName=SYH6K6RMT-P1KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=65036279&lang=en-us
EU RoHS Declaration URL	https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=65036279&lang=en-us
Environmental Profile Availability	https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1511005_EN
End of Life Manual Availability	https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1511005_EN
REACH free of SVHC	No
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty	2 Year
Additional Warranty Information	2 years repair or replace, optional on-site warranties available, optional extended warranties available
