21.5IN FULL HD MONITOR W/PCAP TOUCH

by
ADVANTECH
PCN#
09WZ43
MFG#
FPM-121W-P7AE
$641.29
cps

Extended & Accidental Damage Protection Plans Available Details

  Free Shipping
Estimated Shipment:

Calculating Shipping

Product Highlights:
  • 21.5" Viewable
  • Projected Capacitive
  • 10 Point(s) Multi

Show more

Product Condition: New and Factory Fresh
Shipping Weight: 5 lbs.
Advantech FPM-121W-P7AE 22" Class LED Touchscreen Monitor
Tech Specs
Specifications

Manufacturer

Advantech Co., Ltd

Manufacturer Part Number

FPM-121W-P7AE

Manufacturer Website Address

http://www.advantech.com

Brand Name

Advantech

Product Series

FPM-100W

Product Model

FPM-121W-P7AE

Product Name

FPM-121W-P7AE Touchscreen LED Monitor

Marketing Information

In IIoT and Industry 4.0 era, more and more customers need data to be visualized to benefit process management and decision making. The FPM-100W series is a semi-industrialgrade monitor which provides vivid images and intuitive multi-touch functionalities. Along with its slim and compact design, FPM-100W series is suitable to be placed everywhere that both information display and human interactions are required to increase the production efficiency

Product Type

LED Touchscreen Monitor
Technical Information

Screen Size Class

22"

Viewable Screen Size

21.5"

Screen Mode

Full HD

Panel Technology

Thin Film Transistor (TFT)

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Mount Type

Bracket-mountable

Backlight Technology

LED
Video

Maximum Resolution

1920 x 1080

Color Supported

16.7 Million Colors

Native Contrast Ratio

1,000:1

Brightness

250 Nit
Touchscreen Information

Touchscreen Type

Projected Capacitive

Multi-touch Screen

Yes

Number of Simultaneous Touchpoints

10
Interfaces/Ports

HDMI

Yes

USB

Yes

DisplayPort

Yes

Total Number of HDMI Ports

1

Number of USB Ports

3

Number of DisplayPorts

1
Built-in Devices

Built-in Devices

USB Hub
Environmental Conditions

Operating Temperature Range

32°F (0°C) to 122°F (50°C)
Power Description

Maximum Power Consumption

15 W
Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

100 x 100

Height

12.2"

Width

20.4"

Depth

1.9"

Weight (Approximate)

5.51 lb
