B&B 2-4 WIRE 422/485 CONVERTER WITH TERMINAL BLOCKS

Name: B&B 2-4 WIRE 422/485 CONVERTER WITH TERMINAL BLOCKS
Brand: ADVANTECH
SKU: UN2918
Price: 89.45 USD
Availability: InStock

ADVANTECH

PCN#

UN2918

MFG#

4WSD9TB

$89.45

Extended & Accidental Damage Product Replacement Plan Available Details

1-Year $22.99

2-Year $29.99

Free Shipping

Estimated Shipment:

Product Highlights:

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 1 lbs.

B&B 2-4 WIRE 422/485 CONVERTER WITH TERMINAL BLOCKS

Tech Specs

Specifications

Manufacturer	Advantech Co., Ltd
Manufacturer Part Number	4WSD9TB
Manufacturer Website Address	http://www.advantech.com
Brand Name	B+B SmartWorx
Product Model	4WSD9TB
Product Name	Convert RS-232 to 422/485 with Port Power
Marketing Information	These port-powered RS-232 to 422/485 converters change TD and RD RS-232 lines to 422/485 signals. All of our serial port converters feature Automatic Send Data Control. SDC automatically enables the RS-485 driver when data is present on the RS-232 side. Control of the driver is automatic at rates up to 115.2 kbps.
Packaged Quantity	1
Product Type	Data Transfer Adapter

Technical Information

Adapter Type	Serial
Connector Type on First End	DB-9 RS-232 Serial - Female
Connector on First End Details	1 x 9-pin DB-9 RS-232 Serial Female
Connector Type on Second End	Terminal Block RS-422/485 Serial
Connector on Second End Details	1 x Terminal Block RS-422/485 Serial

Physical Characteristics

Miscellaneous

Certifications & Standards	CE EN 55022 EN 61000-6-1 EN 61000 (-4-2, -4-3, -4-4, -4-5, -4-6, -4-8, -4-11)
Country of Origin	United States
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

Lifetime
